Small Channel X Ray Baggage Scanner for Schools / Hotels / Subway Station

X-ray Inspection System

Model: XST-5030C ------Typical Steel penetration 32mm

Designed to thwart the cleverest attempts at hiding weapons, drugs, stolen goods and other contraband, XST-5030C X-ray inspection systems are ideal for screening everything from small packages to oddly shaped items and palletized loads.

Tunnel Size:500(Width) *300(Height)mm

Dimensions: 1830mm(Length) *810(Width)mm * 1480mm(Height)

Approximate Gross weight: 500kgs

XST-5030C X-ray Baggage scanner

General Specification

Tunnel Size 500(W)*300(H)mm

Conveyor Speed 0.22m/s

Conveyor Max Load 100kg

Dose per Inspection <2.9 μGy/h

Resolution <0.101mm Metal Wire

Penetration 32mm Steel

Film Safety Guarantee ISO1600 Film

X-ray Leakage <0.05 μGy/h (at a distance of 5cm From external housing)

X-ray Generator

● Generate direct: Bottom to up

● Generate anger: 80 degree

● Anode Voltage…………100~160Kv

● Anode power…………0.4 to 1.2mA

● Cooling / Duty Cycle………Oil Cooling /100%

Image System

X-ray Sensor………………L-Shaped Photodiode Array (monoenergetic) , 12bit Deep

Monitor……………………High Resolution Color, LCD Accord, 17 inch

Image Processing…………Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.

Image Grey Level……………4096

Image Max Resolution………1024 * 1280 pixel

Image Processing……………24bit for processing real time

Image storage……………Storage 60000 pictures in real time

Zones & Zoom……………1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation

Multi-energetic distinguish objects …………organic objects in orange, inorganic objects in blue, mixture in green

High-energy/low energy ………………………switch from high energy to low energy

Assist to detect drug and explosive powder

Installation Data

Operation temperature/Humidity…… 0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity……… -20℃-60℃/20%-95%(non-condensing)

Operation Power………………………220VAC(±10%)50±3Hz

Power Consumption……………………1.0 KW (max)

Noise: <55db
