Automatic Sliding Glass Door System HIPHEN SOLUTION SERVICES LTD.

Main Features:

1) Advanced and reliable microprocessor controller are applied.

2) Brushless motor with a long life span and energy conservation.

3) Opening & Closing Speed adjustable.

4) Automatic reverse on obstruction

5) Automatic / open/ closed/ half-open status can be set as need.

6) Automatic adjustment and manual adjustment are available.

7) Simple and convenient installation.

8) Opening and closing smooth with low noise.

9) Interlock and electric lock function support multiple access control systems.

10) With high load capacity, it can also stand heavy door leave.



Technical Parameters:



Configuration
Single-leaf
Double-leaf
Guide Rail 2100mm-6000mm
Max Door Weight
1*150kgs
2*120kgs
Door Width 750-1600mm 650-1250mm
Power
AC 110V-220V ,50-60HZ
AC 110V-220V ,50-60HZ
Motor Brushless DC 24V,65W
Opening speed(adjustable)
200-450mm/s
200-450mm/s
Closing Speed(adjustable)
200-450mm/s
200-450mm/s
Hold Open Time(adjustable)
0-9s
0-9s
Manual Force
<40N
<50N
Sliding Noise
<55 DB
Power Consumption
70w
Ambient Temperature -20~+50℃
