Hauling is a very lucrative business owing to the fact that Nigerians import a large number of goods, aside from that, our local industries need these trucks to haul their goods and services. This article will give a clear insight into the price of Shacman tractor heads in Nigeria. It will cover the price of brand new tractor heads, tokunbo, and locally used tractor heads in Nigeria.
Table of Contents
Models of Shacman tractor head available in the country
We have two classes of Shacman tractor heads in Nigeria, they are popularly known as the long frame and short frame. The long frame is 6 X 4 while the short frame is 4 X 2. I will drop the full specifications of both models. The data was gotten from the official Shacman website.
Specifications of the 6X4 Shacman tractor head
| MODEL | SX4255JT324 |
| DRIVE | 6 X 4 |
| WEIGHT | |
| Complete kerb mass (kg) | 9300 |
| GVW (kg) (legal”/Technical)) | 20500/33500 |
| GCW (kg) (legal”) | 49000 |
| CMT (kg)2 (towing capacity) | 60000 |
| DIMENSIONS | |
| Overall dimensions (LXWXH) (mm) | 6825x2490x3710 |
| Wheel base (mm) | 3225+1350 |
| PERFORMANCE | |
| Maximum speed (km/h) | 100 |
| Minimum turning radius (m) | 8 |
| Minimum turning radius (m) | 33 |
| ENGINE | |
| Brand | WEICHAI |
| Model | WP10.380E32/E22 |
| Power (kw/hp) | 280/380@2400rpm |
| Displacement (L) | 9.726 |
| Maximum torque(N.m)/rpm | 1460/1400-1600 |
| Emission standards | Euro II |
| TRANSMISSION | |
| Brand | FAST |
| Model | 10JSD180/RTD11509C |
| CLUTCH | |
| Type | Single plate, diaphragm spring |
| Diameter(mm) | Eaton Ø430 |
| BRAKES | |
| Type | Drum |
| Service break | Dual circuit compressed air brake |
| Park brake | Power spring break acting on the rear wheel |
| Auxiliary brake | WEVB |
| Optional | ABS |
| STEERING | |
| Type | Integral circulating ball power steering |
| Optional | ZF8098 |
| CHASSIS | |
| Type | Parallel straight ladder structure of “C” type section |
| SUSPENSION | |
| Front suspension | Semi-elliptic leaf springs |
| Rear suspension | Trapezoidal leaf springs |
| AXLES | |
| Brand | HANDE |
| Front axle | 7500kg |
| Rear-axle | 2 x 16000kg, double reduction axle with inter-wheel differential and differential lock |
| Ratio | 4.8(optional 4.42) |
| TIRES | |
| Type (standard) | 12R22.5 |
| FUEL TANK | |
| Tank capacity (L) | 400 (Aluminum) |
| ELECTRICS | |
| Type | 24V |
| Battery | 2×135/Ah |
| CAB | |
| Type | MAN F2000, Lengthened high roof |
| Equipment | 2 rear windows Mechanical sunroof Hydraulic suspension of the cab Hydraulic driver seat with seat belt One sleeping bed Hydraulic reversal Radio with mp3 player |
| Optional | Electric windows Electric reversal cab Electricity heated rearview mirror Air conditioning Air suspension driver seat with seat belt 4 point air suspension of cab Tachograph Cruise control system GPS Air deflector |
| ORDER | |
| The fifth wheel | 3.5 inch |
| Saddle ground clearance (mm) | 1400 |
Specifications of the 4X2 SX4185JT361 Shacman tractor head in Nigeria
The short frame as it’s popularly called comes with a 4 X 2 drive. It comes with lesser power, although the difference is not that much. Both produce 20/340 horsepower. Check out the full specifications below:
| MODEL | SX4185JT361 |
| DRIVE | 4 X 2 |
| WEIGHT | |
| Complete kerb mass (kg) | 7400 |
| GVW (kg) (legal”/Technical)) | 18000/20,500 |
| GCW (kg) (legal”) | 43000 |
| CMT (kg)2 (towing capacity) | 58000 |
| DIMENSIONS | |
| Overall dimensions (LXWXH) (mm) | 6150x2490x3825 (with deflector) |
| Wheel base (mm) | 3500 |
| PERFORMANCE | |
| Maximum speed (km/h) | 90 |
| Minimum turning radius (m) | 7.5 |
| Minimum turning radius (m) | 25 |
| ENGINE | |
| Brand | WEICHAI |
| Model | WP10.340E32/E22 |
| Power (kw/hp) | 280/340@2400rpm |
| Displacement (L) | 9.726 |
| Maximum torque(N.m)/rpm | 1460/1400-1600 |
| Emission standards | Euro II |
| TRANSMISSION | |
| Brand | FAST |
| Model | 10JSD140/RTD11509C |
| CLUTCH | |
| Type | Single plate, diaphragm spring |
| Diameter(mm) | Eaton Ø430 |
| BRAKES | |
| Type | Drum |
| Service break | Dual circuit compressed air brake |
| Park brake | Power spring break acting on the rear wheel |
| Auxiliary brake | WEVB |
| Optional | ABS |
| STEERING | |
| Type | Integral circulating ball power steering |
| Optional | ZF8098 |
| CHASSIS | |
| Type | Parallel straight ladder structure of “C” type section |
| SUSPENSION | |
| Front suspension | Semi-elliptic leaf springs |
| Rear suspension | Trapezoidal leaf springs |
| AXLES | |
| Brand | HANDE |
| Front axle | 7500kg |
| Rear-axle | 16000kg, double reduction axle with inter-wheel differential and differential lock |
| Ratio | 4.8(optional 4.42) |
| TIRES | |
| Type (standard) | 12R22.5 |
| FUEL TANK | |
| Tank capacity (L) | 400 (Aluminum) |
| ELECTRICS | |
| Type | 24V |
| Battery | 2×135/Ah |
| CAB | |
| Type | MAN F2000, Lengthened flat roof |
| Equipment | 2 rear windows Mechanical sunroof Hydraulic suspension of the cab Hydraulic driver seat with seatbelt One sleeping bed Hydraulic reversal Radio with mp3 player Air deflector |
| Optional | Electric windows Electric reversal cab Electricity heated rearview mirror Air conditioning Air suspension driver seat with seatbelt 4 point air suspension of a cab |
| ORDER | |
| The fifth wheel | 2 inch |
| Saddle ground clearance (mm) | 1400 |
Price of brand new Shacman tractor head in Nigeria
The price of brand new Shacman tractor head in Nigeria starts from 35,000,000 to 37,000,000 Naira. The price covers both customs duty and other documents.
Price of tokunbo Shacman tractor head in Nigeria
The price of tokunbo tractor head in Nigeria depends on the year of production, condition, and model. The price ranges from 65,000,000 to 77,000,000 Naira.
Price of Nigerian used Shacman tractor head
The price of a Nigerian used tractor head in Nigeria starts from 40,000,000 to 55,000,000 Naira.
Where can I buy a Shacman tractor head in Nigeria
Getting a Shacman truck can be stressful if you don’t a good contact either from the company or the direct dealers. I will advise you to go through our listing on brand new, tokunbo, and locally used Shacman tractor head for sale in Nigeria.
If you need a direct dealer to talk to a direct dealer, contact Alpha Luxury Wheels Limited (RC: 1884142) on 08107992356.
